JONSBO MOD5 Open Type ATX Mid Tower Gaming Computer Case (Pre Order)

JONSBO MOD-5 Open Type ATX Mid-Tower Gaming Case

Design & Build

• Part of the “Mecha/MechWarrior” inspired design line with an open-air, modular structure.

• Frame made of 2–3 mm aluminum alloy with 4 mm tempered glass panels for durability and visibility.

• Industrial sand-blasted finish for a premium look.

Size & Weight

• Dimensions: 255 mm (W) × 635 mm (H) × 600 mm (D)

• Weight: ~9 kg

Motherboard & Storage Support

• Compatible with ATX, Micro-ATX, Mini-ITX, and in some versions E-ATX up to 287 mm.

• Storage options:

  • Up to 4 × 3.5″ drives, or

  • Mixed setups with 2.5″ and 3.5″ bays.

Cooling & Airflow

• Open-air layout designed for high airflow.

• Fan support:

  • Front: 3 × 120 mm

  • Bottom: 3 × 120 mm

  • Top: 2 × 120 mm

  • Rear: 1 × 120 mm

• Radiator support:

  • Up to 360 mm (front/bottom)

  • Up to 240 mm (top)

  • Supports multi-radiator setups (e.g., dual 360 + one 240).

• Max CPU cooler height: 180 mm

• Max GPU length: 400 mm

Power & Expansion

• Supports ATX power supplies up to 220 mm.

• 7 expansion slots.

• Front I/O ports:

  • 2 × USB 3.0 (Type-A)

  • 1 × USB 3.1 Gen2 (Type-C, 10 Gbps)

  • Audio in/out and microphone jacks
